1/4inch 1million pixel S mount 2.1mm pinhole mini lens
Pinhole lenses are designed for Hidden cameras that hide or disguise in everyday items while recording audio and video. They also can be used for a variety of purposes such as Digital Photography, TV Telephones, Video Conferencing, Covert Surveillance, Barcode Scanning, Medical Systems. Pinhole cone lenses help cameras to capturing images, storing them on a memory card, or transferring them in real time to a remote device. Jinyuan Optics pinhole lens 1/4inch 2.1mm are designed to work with 1/4inch and 1/5inch 650 TV line security camera.2.1mm focal length provide a wide and clear vision to observe a large area with no message or detail missed. Standard M12*0.5 threads make installation easy. With F2.4 aperture, provides realistic colors and clear photos to help you analyze information more accurately.
Products specificate
| Model NO | JY-14PH021FB-MP | |||||
| Aperture D/f' | F1:2.4 | |||||
| Focal-Length (mm) | 2.1 | |||||
| Format | 1/4'' | |||||
| Resolution | MP | |||||
| Mount | M12X0.5 | |||||
| FOV（4.5*3.6*2.7） | 130°/90°/60° | |||||
| MOD | 30cm | |||||
| Operation | Zoom | Fixed | ||||
| Focus | Fixed | |||||
| Iris | Fixed | |||||
| Operating Temerature | -10℃~+60℃ | |||||
| Back Focal-Length (mm) | 2.9mm | |||||
| Flange Back Focal-Length | 2.3mm | |||||
Products Features
● Focal length:2.1mm pinhole
● Support 1/4inch and smaller sensor
● Mount type: standard M12*0.5 threads
● Wide angle pinhole Lens for hidden camera, surveillance Lens, doorbell video Lens IR Cut and Lens Holder are available as per request.
● Environmentally friendly design, no environmental impacts are used in optical glass materials, metal aterials and package material
● Support ODM/OEM
Application Support
If you need any support in finding suitable lens for your camera, please do kindly contact us with further details, our highly skilled design team and professional sales team would be glad to assist you. We are committed to providing customers with cost-effective and time-efficient optics from R&D to finished product solution and maximize the potential of your vision system with the right lens.
