1inch C mount 10MP 25mm Machine vision industrial lens
Product Specifications
| No. | ITEM | Parameter | |||||
| 1 | Model number | JY-01FA25M-10MP | |||||
| 2 | Format | 1"(16mm) | |||||
| 3 | Wavelength | 420~1000nm | |||||
| 4 | Focal Length | 25mm | |||||
| 5 | Mount | C-Mount | |||||
| 6 | Aperture range | F1.8-close | |||||
| 7 | Angel of view (D×H×V) |
1" | 36.21°×29.08°×21.86° | ||||
| 1/2'' | 18.45°×14.72°×11.08° | ||||||
| 1/3" | 13.81°×11.08°×8.34° | ||||||
| 8 | Object dimension at minimum object distance | 1" | 92.4×73.3×54.6mm | ||||
| 1/2'' | 45.5×36.4×27.2㎜ | ||||||
| 1/3" | 34.2×27.3×20.5mm | ||||||
| 9 | Back focus（in air） | 12.6mm | |||||
| 10 | Operation | Focus | Manual | ||||
| Iris | Manual | ||||||
| 11 | Distortion rate | 1" | -0.49%@y=8㎜ | ||||
| 1/2'' | -0.12%@y=4.0㎜ | ||||||
| 1/3" | -0.06%@y=3.0㎜ | ||||||
| 12 | M.O.D | 0.15m | |||||
| 13 | Filter screw size | M30.5×P0.5 | |||||
| 14 | Temperature | -20℃～+60℃ | |||||
Product Introduction
Jinyuan Optics’ 1inch C mount FA / Machine Vision fixed focal length lenses incorporate advanced technologies in compact appearance to provide Ultra high optical quality even in minimum object distance, Provides an ideal solution for a wide range of image processing applications. This series is designed for producing images on sensors up to 10MP, and features locking manual focus and iris rings for use in tough environments such as robot mounted applications, ensure stable focusing. The lens is designed to minimize distortion while maintaining high contrast in order to provide the best images across a wide resolution range from 12mm to 50mm.
Product Features
Focal length: 25mm
Large aperture F2.0 to F22
Perfect for Large Format 1" Megapixel Applications
Suitable with sensors such as Sony’s IMX990, IMX991, and more.
Very good brightness in the peripheral areas
M42-Mount has a 17.526mm flange back distance, but different adapters are available to match other M42-Mount flange back standards.
Unique mechanical design protects against strong vibration and shock.
Environmentally friendly design - no environmental impacts are used in optical glass materials, metal materials and package material
Application Support
If you need any support in finding suitable lens for your camera, please do kindly contact us with further details, our highly skilled design team and professional sales team would be glad to assist you. We are committed to providing customers with cost-effective and time-efficient optics from R&D to finished product solution and maximize the potential of your vision system with the right lens.
Warranty for one year since your purchase from original manufacturer.
