1inch C mount 10MP 50mm Machine vision lenses
Product Specifications
| No. | ITEM | Parameter | |||||
| 1 | Model number | JY-01FA50M-10MP | |||||
| 2 | Format | 1"(16mm) | |||||
| 3 | Wavelength | 420~1000nm | |||||
| 4 | Focal Length | 50mm | |||||
| 5 | Mount | C-Mount | |||||
| 6 | Aperture range | F2.0-F22 | |||||
| 7 | Angel of view (D×H×V) |
1" | 18.38°×14.70°×10.98° | ||||
| 1/2'' | 9.34°×7.42°×5.5° | ||||||
| 1/3" | 6.96°×5.53×4.16° | ||||||
| 8 | Object dimension at MOD | 1" | 72.50×57.94×43.34mm | ||||
| 1/2'' | 36.18×28.76×21.66㎜ | ||||||
| 1/3" | 27.26×21.74×16.34mm | ||||||
| 9 | Back Focal-Length （in air） | 21.3mm | |||||
| 10 | Operation | Focus | Manual | ||||
| Iris | Manual | ||||||
| 11 | Distortion rate | 1" | -0.013%@y=8.0㎜ | ||||
| 1/2'' | 0.010%@y=4.0㎜ | ||||||
| 1/3" | 0.008%@y=3.0㎜ | ||||||
| 12 | M.O.D | 0.25m | |||||
| 13 | Filter screw size | M37×P0.5 | |||||
| 14 | Operation Temperature | -20℃～+60℃ | |||||
Product Introduction
Fixed focal length lenses are commonly used optics in machine vision, being affordable products that are well suited for standard applications. Jinyuan Optics 1 "C Series fixed focal length lenses are specifically designed for machine vision applications, considering the working distance and resolution requirements for factory automation and inspection. The series fixed focal length lenses feature large maximum apertures, making these high-performance lenses usable even in the most stringent lighting conditions. This series is designed for producing images on sensors up to 10MP, and features locking manual focus and iris rings for use in tough environments such as robot mounted applications.
Product Features
Focal length: 50mm
Large aperture: F2.0
Mount type: C mount
Support 1inch and smaller sensor
Locking set screws for the manual focus and iris controls
High resolution: Using high resolution and low dispersion lens elements, resolution up to 10Megapixel
Wide range of operation temperature: Excellent high and low temperature performance, operation temperature from -20℃ to +60℃.
Environmentally friendly design - no environmental impacts are used in optical glass materials, metal materials and package material
Application Support
If you need any support in finding right lens for your application, please do kindly contact us with further details, our highly skilled design team and professional sales team would be glad to assist you. To maximize the potential of your vision system, we will provide fast, efficient, and knowledgeable support. Our primary objective is to match each customer to a right lens that will meet their needs.
Warranty for one year since your purchase from original manufacturer.
